Arash R. Zandieh, MD

A 34-year-old male presented with worsening numbness and increasing weakness in the right hand, progressing to involve the proximal right upper extremity. No family history of VHL. Outside brain MRI revealed a lesion in the cervicomedullary junction, further work-up with dedicated spinal MRI as shown.



There is an intramedullary mass arising in the posterior aspect of the spinal cord, associated with intraspinal cysts and the presence of a well-circumscribed peripheral, nodular enhancing soft tissue component along the dorsal subpial surface. There is some mild peritumoral spinal cord edema and some mild associated expansion/remodeling of the cervicomedullary junction.

This lesion was ultimately resected and surgical pathology revealed hemangioblastoma.




Spinal cord hemangioblastomas are low-grade, vascular neoplasms accounting for a small fraction of all spinal tumors (1.6% to 5.8%). Roughly two-thirds of cases occur sporadically and the remainder occurs in the setting of von Hippel-Lindau (VHL) disease. Once a lesion is found, the patient should undergo contrast-enhanced MRI of the entire neuroaxis (brain through whole spine) to exclude multiple hemangioblastomas, which raises greater suspicion for VHL.

Imaging features of hemangioblastoma can be variable and the lesion can be cystic, solid, hemorrhagic, or mixed in appearance. The lesions typically arise along the posterior aspect of the spinal cord along subpial surfaces and large lesions may demonstrate vascular flow-voids, manifested as serpiginous low signal intensity on T2-weighted images, reflecting enlarged feeding and draining vessels. The lesions may remodel/expand the spinal canal, as in the case shown here. T1-weighted images typically reveal a lesion iso-intense with the spinal cord, which is often difficult to distinguish. On T2-weighted images, the mass is usually hyperintense to CSF in a uniform fashion and there is often peritumoral edema.

A characteristic imaging feature is the presence of an enhancing mural nodule in a cystic lesion, as shown in this case. The solid component of hemangioblastomas typically has a well-circumscribed appearance with intense, homogenous enhancement, which can sometimes help differentiate them from astrocytomas, which tend to have more heterogeneous enhancement.
Patients may present with nonspecific sensory or motor neurologic symptoms. Most spinal lesions producing clinical symptoms have an associated syrinx. The typical age at presentation is a young adult in their 30s, but patients with family history of VHL may present earlier. The tumors grow slowly and do not undergo malignant transformation.

Treatment options include microsurgical resection or stereotactic radioablation. Radiosurgical ablation has a greater role in patients with multiple lesions or inoperable lesions. Preoperative arterial embolization also has some role in the treatment approach.


1. Shah, LM. Diagnostic Imaging: Spine. Lippincott Williams & Wilkins Publishing; 2

  ed. 2010.

2. Baker KB et al. MR imaging of spinal hemangioblastoma.

 2000;174:377-382.

3. Leung RS et al. Imaging features of von Hippel-Lindau disease

Image IQ: 9-year-old Male with Abdominal Pain

Image IQ: Contralateral Breast after Cancer Diagnosis

Poll

34-year-old male presented with worsening numbness and increasing weakness in right hand, progressing to proximal right upper extremity.

Image IQ: 34-year-old Male, Worsening Numbness and Weakness

A 72 year-old woman presents for routine screening mammogram with no complaints.

Conventional mammographic craniocaudal (CC) and mediolateral oblique (MLO) views demonstrate a developing focal asymmetry in the right breast, which has gradually increased over multiple prior examinations. The margins are spiculated and there is associated architectural distortion, resulting in tethering and indentation of nearby fibroglandular breast parenchyma. Targeted sonography reveals a heterogeneous hypoechoic 1.6 cm mass at 11:00 radian with indistinct, irregular angular margins, mild posterior shadowing and mild surrounding echogenic rim. MRI reveals an irregular enhancing mass with spiculated margins and rapid enhancement with washout kinetics. No other suspicious lesions were seen on MRI, including detailed review of the contralateral breast. Diagnosis was confirmed with ultrasound-guided core needle biopsy.

Invasive lobular carcinoma (ILC) comprises 10-15 percent of all invasive breast cancers and is the second most common invasive breast carcinoma after invasive ductal carcinoma NOS (not otherwise specified). ILC can be a subtle diagnosis, often resulting in misdiagnosis or delayed diagnosis. ILC typically presents as a vague developing asymmetry. A detailed review of multiple prior examinations is often required to demonstrate gradual changes of developing asymmetry, which may not be apparent on a single year-to-year basis.

ILC is an insidious process characterized by a loss of normal cellular adhesion, insinuating through the breast in a sheet-like manner, usually without inducing the intense desmoplastic reaction that typically accompanies invasive ductal carcinoma. The histopathologic hallmark is a loss of E-cadherin, resulting in cellular infiltration in "single-file" or column-like fashion.

Ultrasound and breast MR offer higher sensitivity for detection than mammography alone, with MRI providing the best characterization for overall extent of disease. MR offers high sensitivity for the detection of additional malignant lesions in ILC, which may be bilateral, multicentric, or multifocal. ILC may also co-exist with lobular carcinoma in-situ or atypical lobular hyperplasia.

Berg, WA, Yang WT. Diagnostic Imaging: Breast, 2nd Ed. Amirsys. 2013.

Ikeda, DM. Breast Imaging: The Requisites. Elsevier, Inc. 2004.

Albayrak ZK, et al. Invasive lobular carcinoma of the breast: Mammographic and sonographic evaluation.

A 72 year-old woman presents for routine screening mammogram with no complaints.
